Technical Data
- Raw Material
- 2.2–6.6 dtex × 51–65 mm Pre-oxidized fiber
- Width
- Max 2400 mm (Double width 1200 × 2)
- Basis Weight
- 100–400 g/㎡ (Max 900 g/㎡)
- Speed
- 1.5–7.5 m/min (Max 9.0 m/min @ 60Hz)
- Capacity
- ≈ 340 kg/h (Approx. 6800 kg/day, based on 20h)
- Needling Density (Main)
- 337–674 punches/cm²
- Needling Density (Finishing)
- 163–326 punches/cm²
- Needling Density (Total)
- 500–1000 punches/cm²
